Tp-Link Omada EAP727 7 UR - BE5000 5-Stream Ceiling Mount Dual-Band Wi-Fi 7 Access Point

New

Tp-Link Omada EAP727 7 UR - BE5000 5-Stream Ceiling Mount Dual-Band Wi-Fi 7 Access Point

Product Code:
Availability:

Tp-Link Omada EAP727
In Stock

5-Stream Wi-Fi 7: 4,324 Mbps on 5 GHz and 688 Mbps on 2.4 GHz.

1× 2.5G PoE+ Port: Ensures high-speed connectivity throughout the network.

Low Latency and Interference: 160 MHz bandwidth, Multi-Link Operation, Multi-Rus, and 4K-QAM ensure high performance for your connectivity.

Flexible Deployment and Easy Setup: Supports 802.3at PoE or DC power supply for flexible installation with Omada SDN for one-click setup.

Advanced Features: Supports centralized cloud management, PPSK, multiple portals, mesh, and seamless roaming.

More Connections and Wider Coverage: Supports 510+ concurrent connections** and covers up to 2,000 ft² (185 m²)* for reliable and extensive wireless connectivity.

Description

Hardware Features
Interface	1× 2.5 Gbps Ethernet Port
Button	Reset
Power Supply	802.3at PoE 12V/1.5A DC Note: DC power adapter is not included. DC power interface: 12V, accepts 2.1 mm / 5.5 mm center-positive circular plug with 9 mm length.
Weight	0.47 kg (1.04 lb)
Dimensions (W × D × H)	6.3 × 6.3 × 1.4 in (160 × 160 × 36.7 mm)
Antenna	2.4 GHz: 2 × 4 dBi 5 GHz: 3 × 6 dBi
Bluetooth	1 × 4 dBi (peak gain), internal antenna
Mounting	Ceiling/Wall/Junction Box Mounting (Kits included) T-Bar Mounting (Kits included)
Max. Power Consumption	17.5 W (PoE) 15.8 W (DC)

Management Features
Omada App	Yes (Omada App V5.0 and above)
Centralized Management	Omada Central (Cloud-Based) Omada Hardware Controller Omada Software Controller
Cloud Access	Yes. Requires the use of Omada Controller.
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1, v2c, v3
System Logging Local/Remote Syslog	Yes
SSH	Yes
Web-based Management	Yes

Wireless Features
Coverage	2,000 ft² (185 m²)*
Concurrent Clients	510+**
Wireless Standards	IEEE 802.11 a/b/g/n/ac/ax/be
Frequency	2.4 GHz and 5 GHz
Signal Rate	688 Mbps (2.4 GHz) + 4324 Mbps (5 GHz)
Wireless Functions	MLO 4K-QAM Seamless Roaming 160 MHz Bandwidth Mesh OFDMA Load Balance Band Steering Beamforming Airtime Fairness Multiple SSIDs: 16 (8 on each band) Wireless Schedule Reboot Schedule QoS (WMM) Rate Limit Static IP/Dynamic IP RADIUS Accounting MAC Authentication
Wireless Security	Captive Portal Authentication Access Control MAC Filter Wireless Isolation Between Clients VLAN Rogue AP Detection WPA-Personal/Enterprise WPA2-Personal/Enterprise WPA3-Personal/Enterprise
Transmission Power	4–26 dBm (2.4 GHz) 6–27 dBm (5 GHz, U-NII-1 & U-NII-2A & U-NII-2C & U-NII-3)

Others
Certification	FCC/CE/VCCI/JRF/ICES
Package Content	EAP727 Installation Guide Mounting Kit
Environment	Operating Temperature: 0℃ to +40℃ (32℉ to +104℉) Storage Temperature: -40℃ to +70℃ (-40℉ to +158℉) Operating Humidity: 10% to 90% (non-condensing) Storage Humidity: 5% to 90% (non-condensing) Storage Altitude: up to +2000 m (6561 feet) Operating Altitude: up to +2000 m (6561 feet)
