Tp-Link Omada EAP770 7 Pro - BE11000 6-Stream Ceiling Mount Tri-Band Wi-Fi 7 Access Point with Power Adapter

Product Code:
Availability:

Tp-Link Omada EAP770
In Stock

BE11000 Tri-Band Wi-Fi 7: 5765 Mbps (6 GHz) + 4324 Mbps (5 GHz) + 688 Mbps (2.4 GHz). Buffering will no longer be a problem.

1× 2.5G Port: Unlock the full potential of Wi-Fi 7.

Clear 6 GHz Band: Brings cleaner and wider band resources to your Wi-Fi.

320 MHz Bandwidth: Up to 320 MHz bandwidth enables many more simultaneous transmissions at the fastest possible speeds.

Low Latency and Interference: Multi-Link Operation, and Multi-RUs ensure high performance of your network.

Advanced Functions: Supports centralized management, Mesh, and Seamless Roaming.

Description

Omada EAP770 Specifications

Hardware Features
Interface	1 × 2.5G Ethernet Port
Button	Reset
Power Supply	802.3at PoE or 12V/2.5A DC
Max. Power Consumption	25.4 W (For PoE) 21.8 W (For DC)
Dimensions (W × D × H)	8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
Antenna	2.4 GHz: 2 × 4.0 dBi 5 GHz: 2 × 5.0 dBi 6 GHz: 2 × 5.0 dBi
Bluetooth	1 × 4.0 dBi, Bluetooth 5.2 *Firmware update may be required.
Mounting	Ceiling / Wall / Junction Box Mounting (Kits Included)
Management Features
Omada App	Yes
Centralized Management	Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller
Cloud Access	Yes. Requires the use of an Omada controller.
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1, v2c, v3
System Logging (Local/Remote Syslog)	Yes
Web-based Management	Yes
Wireless Features
Coverage	1500 ft² (140 m²)
Concurrent Clients	380+**
Wireless Standards	IEEE 802.11 a/b/g/n/ac/ax/be
Frequency	6 GHz, 5 GHz, and 2.4 GHz
Signal Rate	688 Mbps (2.4 GHz) + 4324 Mbps (5 GHz) + 5765 Mbps (6 GHz)
Wireless Functions	MLO 4K-QAM MU-MIMO 320 MHz Bandwidth Mesh Seamless Roaming (802.11k/v/r) BSS Coloring OFDMA Load Balance Band Steering Beamforming Airtime Fairness Multiple SSIDs: 24 (8 on each band) Wireless Schedule Reboot Schedule QoS (WMM) Rate Limit Static IP/Dynamic IP RADIUS Accounting MAC Authentication
Wireless Security	Captive Portal Authentication Access Control Maximum number of MAC Filter: 4,000 Wireless Isolation Between Clients VLAN Rogue AP Detection WPA-Personal/Enterprise WPA2-Personal/Enterprise WPA3-Personal/Enterprise
Transmission Power	< 25 dBm (2.4 GHz) < 25 dBm (5 GHz) < 23 dBm (6 GHz)
Others
Certification	CE, FCC, IC
Package Content	Omada Ceiling Mount Access Point EAP770 Installation Guide Power Adapter Ceiling/Wall/Junction Box Mounting Kits
Environment	Operating Temperature: 0 °C–40 °C (32 °F–104 °F) Storage Temperature: -40 °C–70 °C (-40 °F–158 °F) Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing
