Tp-Link Omada EAP775-Outdoor 7 Pro Outdoor BE11000 6-Stream Directional/Omnidirectional Outdoor Tri-Band Wi-Fi 7 Access Point
New
Tp-Link Omada EAP775-Outdoor 7 Pro Outdoor BE11000 6-Stream Directional/Omnidirectional Outdoor Tri-Band Wi-Fi 7 Access Point
Product Code:
Availability:
Availability:
Tp-Link Omada EAP775-Outdoor
In Stock
In Stock
Tri-Band 6-Stream Outdoor Wi-Fi 7: Delivers high-speed outdoor connectivity up to 11.0 Gbps.†
6 GHz Band Unlocked by AFC: AFC enables 6 GHz band outdoor uses.*
Plug & Play Automatic Antenna Detection: Automatically detects antenna changes and switches between directional and omnidirectional modes.
Customizable Directional and Omnidirectional Antennas: Individually adjust antenna modes for specific frequency bands via software to meet the precise requirements of complex, speciallized scenarios.**
True Tri-Band Coverage: 3,229 ft2 (300 m2) omnidirectional and 5,500 ft2 (510 m2) directional recommended coverage.
1× 2.5G PoE Port: Flexible PoE deployment reduces costs by delivering power and data over a single Ethernet cable.
Outdoor-Ready Durability: Features an IP68-rated weatherproof enclosure, anti-UV coating, and 6kV lightning protection.
Quick and Easy Setup: Features wall/pole mounting with Omada SDN for one-click setup.
Advanced Features: Centralized management, mesh, and seamless roaming.
Description
| HARDWARE FEATURES | |
|---|---|
| Interface | 1 × 10M/100M/1000M/2.5Gbps Ethernet Port (RJ45) |
| Button | Reset |
| Power Supply | 802.3at PoE |
| Max. Power Consumption | 20.4W (for PoE+) |
| Dimensions (W × D × H) | 8.78 × 6.89 × 2.20 in (223 × 175 × 56 mm) |
| Antenna |
2.4 GHz: • 2 × 4.5 dBi (peak gain), external omnidirectional antennas • 2 × 8.7 dBi (peak gain), internal directional antennas (antenna beamwidth 90° × 75°) 5 GHz: • 2 × 5.3 dBi (peak gain), external omnidirectional antennas • 2 × 10.5 dBi (peak gain), internal directional antennas (antenna beamwidth 90° × 45°) 6 GHz: • 2 × 7.0 dBi (peak gain), internal omnidirectional antennas • 2 × 12.0 dBi (peak gain), internal directional antennas (antenna beamwidth 90° × 30°) *Note: The gains above are the single-antenna peak gains. |
| Bluetooth | BLE 5.2 |
| Weatherproof Enclosure | IP68 |
| Mounting | Pole/Wall Mounting (Kits included) |
| MANAGEMENT FEATURES | |
| Omada App | Yes |
| Centralized Management |
• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Require the use of an Omada controller. |
| Email Alerts | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | Yes |
| SSH | Yes |
| Web-based Management | Yes |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller |
| WIRELESS FEATURES | |
| Wireless Standards | IEEE 802.11a/g/b/n/ac/ax/be |
| Frequency | 2.4 GHz, 5 GHz, 6 GHz |
| Signal Rate | 688 Mbps (2.4 GHz) + 4324 Mbps (5 GHz) + 5765 Mbps (6 GHz) |
| Wireless Functions |
• 4K-QAM • OFDMA • Multiple SSIDs: 24 (8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • MLO • Omada Mesh • Seamless Roaming (802.11k/v/r) • Band Steering • Load Balance • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client • Static IP/Dynamic IP |
| Wireless Security |
• Captive Portal Authentication • Access Control • Wireless MAC Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WPA-Personal/Enterprise • WPA2-Personal/Enterprise • WPA3-Personal/Enterprise • OWE |
| Transmission Power |
FCC: (Conducted Power) 2.4 GHz: 25 dBm 5 GHz: 25 dBm in U-NII-1, 24 dBm in U-NII-2A, 24 dBm in U-NII-2C, 25 dBm in U-NII-3 6 GHz: 25 dBm |
| OTHERS | |
| Certification | CE, FCC, IC, NCC, VCCI, JRF, BSMI |
| Package Content |
• Access Point EAP775-Outdoor • Mounting Kit • Waterproof Kit • Antennas • Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux |
| Environment |
• Operating Temperature: -30 to 70 ℃ (-22 to 158 ℉) • Storage Temperature: -40 to 70 ℃ (-40 to 158 ℉) • Operating Humidity: 10 to 90% RH non-condensing • Storage Humidity: 5 to 90% RH non-condensing |
| Weight | Main Unit: 1.4 kg (3.09 lbs) |
